UPPER PART OF WRECKER TRUCK PARAMETERS

Upper frame structure

The wheelbase requirements of chassis

38000(mm)

Upper part dimensions

5600x2330 (mm)

Rated load capacity

4 TON

Operating Stroke

2700 (mm)

Hydraulic capstan

Hydraulic capstan working pressure

14 MPA

Rated rope speed

8 meter/minute

Length of hydraulic capstan steel wire rope

21M

Hydraulic capstan Rated tension force

4 TON

Hoisting Organ

Rating Under-Pulling Capacity

6000 (kg)

Rating Under-Hoisting Capacity

2000 (kg)

Fully Extended Max Under-Hoisting Capacity

1600 (kg)

Max Under-Hoist Useful Length

1640 (mm)

Remarks

1. Equipped with One Set of Auxiliary Wheels

2. Bundling belt 4pcs

3. Yellow Warning Lamp 1pc

4. Double Side Hydraulic Operation

5. Can Tow 2 Cars

Color

Optional according to customer requirement .

Payment term

BY T/T, 30% DEPOSIT, THE BALANCE WILL BE PAID BEFORE DELIVERY.
